REMA PERFORMANCEline 70

The optimum wear protection solution

REMA PERFORMANCEline 70/CN is the optimum wear protection solution for extreme loads and a premium abrasion resistance. Due to the perfectly matched technical values REMA PERFORMANCEline 70/CN provides an excellent tensile strength, and an improved tear growth resistance. As a result, material Transfers and other system components with wear and impact problems are optimally equipped.


REMA PERFORMANCEline 70/EP160

The optimum fabric reinforced wear protection solution

REMA PERFORMANCEline 70/EP160/CN has been specially designed to withstand extreme wear and caking for a variety of wet or dry applications in challenging operating conditions.


REMALINE 25

The safe protection against wear and material build-up

Thanks to its elastic properties, REMALINE 25 lining is suitable for preventing build-up in equipment conveying sand/water mixtures and fine material. Furthermore, REMALINE 25 lining offers excellent noise dampening and reduction of noise emissions.


REMALINE 35

Premium quality for wet wear and build-up

REMALINE 35 features excellent resistance to wet abrasive and sharp particles. The properties of REMALINE 35 make it the optimum rubber lining for sand and gravel industry equipment as well as in the glass industry. REMALINE 35 lining has also proven valuable with sticky material such as loam and clay.


REMALINE 35/EP160

The fabricreinforced premium quality for wet wear and build-up

REMALINE 35/EP60/CN features excellent resistance to wet abrasive and sharp particles. The properties of REMALINE 35 make it the optimum rubber lining for sand and gravel industry equipment as well as in the glass industry. REMALINE 35 lining has also proven valuable with sticky material such as loam and clay.


REMALINE MP 35

The perfect way to reliable production planning

REMALINE MP 35/CN puts an end to premature, unplanned system downtime and unnecessary maintenance and standstill costs! This new development, which points the way to the future of lining materials, offers you more than just first-class surface protection. It also gives you a timely reminder when the lining needs to be renewed. Thus, you can easily plan and schedule to ensure smooth-running production processes, and significantly increased system productivity. A decisive advantage, particularly where it is difficult to check the thickness of the lining using conventional methods


REMALINE 40

The universal lining for many applications

REMALINE 40/CN has been designed for a variety of wet or dry applications. In dry applications, REMALINE 40 is frequently used for conveying coke. In wet applications, this material has proven its outstanding worth as a protective coating for sharp particles thanks to its high resistance to tearing. REMALINE 40 also features excellent qualities for eliminating bridge formation and build-up.


REMALINE 40 ORANGE

The universal lining for many applications especially for wet abrasion

REMALINE 40 ORANGE has been designed to withstand wear and caking for a variety of applications especially from wet abrasion.


REMALINE 40/EP160

The fabric reinforced universal lining for many applications

REMALINE 40/EP160/CN has been specially designed to withstand wear and caking for a variety of wet or dry applications in challenging operating conditions.


REMALINE 40 OIL

The oil and grease resistant universal lining

REMALINE 40 OIL/CN has been designed for a variety of wet or dry applications in which oil and grease are or might be involved.


REMALINE 40 WHITE FOOD

The universal food lining for many applications

REMALINE 40 WHITE FOOD has been designed for a variety of wet or dry applications. It fulfils the requirements for food contact and can be safety applied in any systems with hygiene requirements. • Federal Institute for Risk Assessment, Recommendations on Food Contact Materials XXI, Cat. 3+4 (Germany) • Regulation (EU) No. 1935/2004 • FDA Regulation No. 21 CFR 177.2600 • Required adhesive system for food contact: CEMENT SC 4000 white/HARDENER E-40 or CEMENT SC 2000 white/HARDENER ER-42


REMALINE MP 40

The perfect way to reliable production planning

REMALINE MP 40 puts an end to premature, unplanned system downtime and unnecessary maintenance and standstill costs! This new development, which points the way to the future of lining materials, offers you more than just first-class surface protection. It also gives you a timely reminder when the lining needs to be renewed. Thus, you can easily plan and schedule to ensure smooth-running production processes, and significantly increased system productivity. A decisive advantage, particularly where it is difficult to check the thickness of the lining using conventional methods.


REMALINE 50

The highly tear-resistant lining

REMALINE 50/CN is suitable for wet applications based on its excellent properties. Thanks to its great elasticity and high tear resistance, it is especially useful for lining pipes, chutes and tanks in power plants and gravel works. Furthermore, it can be used on non-driven pulleys to prevent build-up.


REMALINE 60

The lining for protection from impact wear

Thanks to its low-abrasion properties, REMALINE 60/CN is especially suitable for protecting against impact and dry wear and, based on this, is frequently used for conveying coal. Fur- thermore, non-driven pulleys can be vulcanized with REMALINE 60.


REMALINE 60/EP160

The fabric reinforced lining for protection from impact wear

REMALINE 60/EP160 has been specially designed to withstand wear and caking for a variety of wet or dry applications in challenging operating conditions with high impact energies.


REMALINE MP 60

The perfect way to reliable production planning

REMALINE MP 60 puts an end to premature, unplanned system downtime and unnecessary maintenance and standstill costs! This new development, which points the way to the future of lining materials, offers you more than just first-class surface protection. It also gives you a timely reminder when the lining needs to be renewed. Thus, you can easily plan and schedule to ensure smooth-running production processes, and significantly increased system productivity. A decisive advantage, particularly where it is difficult to check the thickness of the lining using conventional methods.


REMALINE 70 OIL

The oil and grease resistant premium quality for tough wear situations

REMALINE 70 OIL/CN has been specially designed to withstand wear and caking for a variety of wet or dry applications in challenging operating conditions in which oil and grease are or might be involved.


REMALINE 70 OIL/EP160

The fabric reinforced, oil and grease resistant premium quality for tough wear situations

REMALINE 70 OIL/EP160/CN has been specially designed to withstand wear and caking for a variety of wet or dry applications in challenging operating conditions in which oil and grease are or might be involved.


REMALINE 70 V

The self-extinguishing premium quality for tough wear situations

REMALINE 70 V is self-extinguishing and antistatic. It has been specially designed to withstand wear and caking for a variety of wet or dry applications in challenging ATEX operating conditions with high fire regulation or potentially explosive environments. Required adhesive system for antistatic rubber coatings: PRIMER PR 200 and CEMENT SC 4000 black/HARDENER ER-42 or CEMENT SC 2000 black/HARDENER UT-R 20. German underground approval: LOBA No. 18.43.21-89-33 Polish underground approval: Dopuszczenie WUG Katowice No. B/1724/IV/2016


REMALINE 70 HR

The heat resistant premium quality for tough wear situations

REMALINE 70 HR is made to withstand a continuous thermal stress of 110 °C and even short-term stresses of 130°C. It has been specially designed to withstand wear and caking for a variety of wet or dry applications in challenging operating conditions in hightemperature environments. Recommended adhesive system for heat resistant rubber lagging: PRIMER PR 200 and CEMENT PERFORMANCE 140 HT with HARDENER PERFORMANCE 140 HT.


REMALINE 70 WHITE OIL FOOD

The oil and grease resistant premium food quality for tough wear situations

REMALINE 70 WHITE OIL FOOD has been specially designed for a variety of wet or dry applications against wear and caking in challenging operating conditions. It fulfills the requirements for food contact and can be safely applied in any systems with hygiene requirements in accordance with: • Federal Institute for Risk Assessment, Recommendations on Food Contact Materials XXI, Cat. 3+4 (Germany) • Regulation (EU) No. 1935/2004 • FDA Regulation No. 21 CFR 177.2600 • Required adhesive system for food contact: CEMENT SC 4000 white/HARDENER E-40 or CEMENT SC 2000 white/HARDENER ER-42


REMALINE 90

The lining for better material flow

REMALINE 90 is a hard rubber material featuring outstanding sliding properties and wear-resistance. Due to its slippery surface wear and build-up can be efficiently prevented and material flow improved.


REMASTAR

Premium quality with extreme abrasion resistance

REMASTAR is a combination of thermoplastic polyurethane and rubber and features new and significantly improved features compared to existing lining materials. REMASTAR provides excellent resistance to wear caused by cutting and grooving and remains flexible even at low temperatures. The material is resistant to oils, grease and many solvents and also to ageing.


UNILINE 40

The lining for simple applications and wet wear

UNILINE 40 can be universally used as rubber lining for simple applications and wet wear.


UNILINE 60

The lining for simple applications and dry wear

UNILINE 60 can be universally used as rubber lining for simple applications and dry wear.


REMATHAN G 65/CN

High quality polyurethane lining material

REMATHAN premium wear protection plates are a convincing choice thanks to their extremely high wear resistance and their excellent resistance to oil and grease.


REMATHAN G 75/CN

High quality polyurethane lining material

REMATHAN premium wear protection plates are a convincing choice thanks to their extremely high wear resistance and their excellent resistance to oil and grease.


REMATHAN G 90/CN

High quality polyurethane lining material

REMATHAN premium wear protection plates are a convincing choice thanks to their extremely high wear resistance and their excellent resistance to oil and grease.


REMATHAN G 80 FDA/CN

High-quality polyurethane lining material for use in the food industry

REMATHAN premium wear protection plates are a convincing choice due to their extremely high wear-resistance and their excellent resistance to oil and grease. With their special properties REMATHAN offers optimum protection for machines and systems and thus ensuring a longer service life. The REMATHAN FDA quality can be used for contact with dry, aqueous and fatty foods for contact times of up to 30 minutes and at a maximum of 70°C. The material has been tested and approved in accordance with FDA and European Union regulations.


REMATHAN G 75 LB

High-quality polyurethane lining material with perforated metal insert

REMATHAN premium wear protection plates are a convincing choice due to their extremely high wear-resistance and their excellent resistance to oil and grease. With their special properties REMATHAN offers optimum protection for machines and systems and thus a longer service life. Due to the perforated metal insert, the REMATHAN product is strengthened and can be easily and safely bolted. The REMATHAN plates can be cut to the right dimensions directly on your construction site.


Product Information

Properties

  • Superior resistance to wear
  • Excellent resistance to abrasion
  • Extremely high tensile strength
  • Good weather resistance
  • Simple and easy to bond with REMA TIPTOP Premium bonding layer
  • Improved abrasion
  • Improved elongation at break

Area of Application

  • Material transfer points, chutes, bunkers and slides
  • Lining for truck bodies, Impact curtains and vibrating conveyors
  • Lagging for non-driven pulleys with moderate to high belt tension
  • Cold refurbishing of conveyor belts Mill lining

Specifications

Polymer basis NR/BR DIN ISO 1629
Specific Weight 1.12 g/cm3 DIN EN ISO 1183-1
Hardness 65 Shore A DIN ISO 7619-1
Colour Black

Product Information

Properties

  • REMA PERFORMANCEline 70 premium- quality with fabric reinforcement
  • Superior resistance to wear
  • Excellent resistance to abrasion
  • Extremely high tensile strength
  • Good weather resistance
  • Simple and easy to bond with
  • REMA TIPTOP CN bonding layer
  • Improved abrasion
  • Improved elongation at break

Area of Application

  • Material transfer points, chutes, bunkers and slides
  • Lining for truck bodies, impact curtains and vibrating conveyors

Specifications

Polymer basis NR/BR DIN ISO 1629
Specific Weight 1.12 g/cm3 DIN EN ISO 1183-1
Hardness 65 Shore A DIN ISO 7619-1
Colour Black

Product Information

Properties

  • Safe protection against wear and material build-up
  • Highly elastic and flexible
  • Noise damping
  • Wear resistant (round grains)
  • CN bonding layer provides fast and good
  • adhesion

Area of Application

  • Covers for conveyor rollers
  • Lining of elevator buckets and excavator buckets
  • Outlet funnels for dry mortar
  • Flexilo and bunker lining
  • Noise reduction lining

Specifications

Polymer basis NR/IR DIN ISO 1629
Specific Weight 0.97 g/cm3 DIN EN ISO 1183-1
Hardness 33 Shore A DIN ISO 7619-1
Colour Black

Product Information

Properties

  • Highly wear-resistant, especially resistant to wet abrasion
  • Safe protection against material buildup
  • Highly elastic
  • Excellent self-cleaning capability
  • CN bonding layer provides fast and good adhesion

Area of Application

  • Slurry handling
  • Lining of slurry chutes, pipes, pumps, hydro cyclones, flotation cells, tanks and launders for example in the sand and gravel industry
  • Chutes / discharge hoses for ready mixed concrete
  • Lining of excavator buckets to prevent caking

Specifications

Polymer basis NR DIN ISO 1629
Specific Weight 0.96 g/cm3 DIN EN ISO 1183-1
Hardness 33 Shore A DIN ISO 7619-1
Colour Yellow

Product Information

Properties

  • REMALINE 35 premium quality with fabric reinforcement
  • Highly wear-resistant; especially resistant to wet abrasion
  • Safe protection against material buildup
  • Highly elastic
  • Excellent self-cleaning capability
  • CN bonding layer provides fast and good
  • adhesion

Area of Application

  • Slurry handling
  • Lining of slurry chutes, pipes, pumps, hydro cyclones, flotation cells, tanks and launders for example in the sand and gravel industry
  • Chutes / discharge hoses for ready mixed concrete
  • Lining of excavator buckets to prevent caking

Specifications

Polymer basis NR DIN ISO 1629
Specific Weight 0.96 g/cm3 DIN EN ISO 1183-1
Hardness 33 Shore A DIN ISO 7619-1
Colour Yellow

Product Information

Properties

  • Safe protection against wear and materi- al build-up with built-in wear indicator
  • Yellow wear layer
  • Red signal layer
  • Very wear resistant, particularly for wet use
  • Very elastic
  • High self-cleaning effect
  • Noise damping; reduces dust formation
  • CN bonding layer provides fast and good
  • adhesion

Area of Application

  • Especially suitable for conveying components that are hard to access and inspect by conventional methods
  • Lining of drains, pipes, hydrocyclones, flotation cells, tanks, etc for example in the sand and gravel industry
  • Slurry handling
  • Flexilo and bunker lining
  • Lining of excavator buckets to prevent caking

Specifications

Polymer basis NR DIN ISO 1629
Specific Weight 0.96 g/cm3 DIN EN ISO 1183-1
Hardness 33 Shore A DIN ISO 7619-1
Colour Yellow/Red

Product Information

Properties

  • Safe protection against wear and material build-up especially for sharp-edged material
  • High tensile strength
  • High tear growth resistance
  • Highly elastic
  • CN bonding layer provides fast and good adhesion

Area of Application

  • Universally applicable as lining against caking, abrasion and impact
  • Flexilo and hopper lining
  • Lining for coal processing
  • Lagging for non-driven pulleys with low belt tension (build-up protection)

Specifications

Polymer basis NR DIN ISO 1629
Specific Weight 1.05 g/cm3 DIN EN ISO 1183-1
Hardness 50 Shore A DIN ISO 7619-1
Colour Black

Product Information

Properties

  • Safe protection against wear and material build-up especially from wet abrasion
  • Highly elastic
  • Good self-cleaning capability
  • CN bonding layer provides fast and good adhesion

Area of Application

  • Universally applicable as lining for example of slurry chutes, cells, tanks and launders
  • Flexilo and hopper lining
  • Lining for coal processing
  • Lining of excavator buckets to prevent caking
  • Slurry handling

Specifications

Polymer basis NR DIN ISO 1629
Specific Weight 1.05 g/cm3 DIN EN ISO 1183-1
Hardness 44 Shore A DIN ISO 7619-1
Colour Orange

Product Information

  • REMALINE 40 premium quality with fabric reinforcement
  • Safe protection against wear and material build-up especially from wet abrasion
  • Highly elastic
  • Good self-cleaning capability
  • CN bonding layer provides fast and good
  • adhesion

Area of Application

  • Universally applicable as lining against caking, abrasion and impact
  • Flexilo and hopper lining
  • Lining for coal processing
  • Lining of excavator buckets to prevent
  • caking

Specifications

Polymer basis NR DIN ISO 1629
Specific Weight 1.05 g/cm3 DIN EN ISO 1183-1
Hardness 50 Shore A DIN ISO 7619-1
Colour Black

Product Information

Properties

  • Oil and grease resistant REMALINE 40 premium quality
  • Safe protection against wear and material build-up especially from wet abrasion
  • Highly elastic
  • Good self-cleaning capability
  • CN bonding layer provides fast and good
  • adhesion

Area of Application

  • Universally applicable as lining against caking, abrasion and impact
  • Flexilo and hopper lining
  • Lining for coal processing
  • Lagging for non-driven pulleys with low belt tension (build-up protection)
  • Lining of excavator buckets to prevent caking

Specifications

Polymer basis NR DIN ISO 1629
Specific Weight 1.09 g/cm3 DIN EN ISO 1183-1
Hardness 45 Shore A DIN ISO 7619-1
Colour Black

Product Information

Properties

  • Food quality
  • Safe protection against wear and material
  • build-up especially from wet abrasion
  • Highly elastic
  • Good self-cleaning capability
  • CN bonding layer provides fast and good
  • adhesion

Area of Application

  • Special lining for the food industry
  • Universally applicable as lining against caking, abrasion and impact
  • Flexilo and hopper lining
  • Lining of excavator buckets to prevent caking

Specifications

Polymer basis NR DIN ISO 1629
Specific Weight 1.02 g/cm3 DIN EN ISO 1183-1
Hardness 39 Shore A DIN ISO 7619-1
Colour White

Product Information

Properties

  • Safe protection against wear and material build-up with built-in wear indicator
  • Orange wear layer
  • Black signal layer
  • Very wear resistant, particularly for wet use
  • Very elastic
  • High self-cleaning effect
  • Noise damping; reduces dust formation
  • CN bonding layer provides fast and good
  • adhesion

Area of Application

  • Especially suitable for conveying components that are hard to access and inspect by conventional methods
  • Lining of drains, pipes, hydrocyclones, flotation cells, tanks, etc for example in the sand and gravel industry
  • Slurry handling
  • Flexilo and bunker lining
  • Lining of excavator buckets to prevent caking

Specifications

Polymer basis NR DIN ISO 1629
Specific Weight 1.05 g/cm3 DIN EN ISO 1183-1
Hardness 44 Shore A DIN ISO 7619-1
Colour Orange/Black

Product Information

Properties

  • Safe protection against wear and material build up, especially from wet abrasion and sharp-edged material
  • High tear growth resistance
  • High cut resistance
  • CN bonding later provides fast and good adhesion

Area of Application

  • Applications in wet areas such as linings for cool water pipes in power plants for example
  • Lining of chutes, tanks and discharge hoppers for round grains
  • Lagging for non-driven pulleys with low belt traction (prevents caking)

Specifications

Polymer basis NR DIN ISO 1629
Specific Weight 1.11 g/cm3 DIN EN ISO 1183-1
Hardness 51 Shore A DIN ISO 7619-1
Colour Orange

Product Information

Properties

  • Safe protection against wear and material build-up to dry abrasion and impact
  • Good weather resistance
  • CN bonding layer provides fast and good adhesion

Area of Application

  • Lining for vibration chutes, slides, material transfer points, truck bodies, impact curtains, bunkers, silos, chutes and filtering buckets
  • Lagging for non-driven pulleys with moderate to high belt traction

Specifications

Polymer basis BR/IR/SBR DIN ISO 1629
Specific Weight 1.13 g/cm3 DIN EN ISO 1183-1
Hardness 60 Shore A DIN ISO 7619-1
Colour Black

Product Information

Properties

  • REMALINE 60 premium quality with fabric reinforcement
  • Safe protection against wear and material build-up to dry abrasion and impact
  • Good weather resistance
  • CN bonding layer provides fast and good adhesion

Area of Application

  • Lining for vibration chutes, slides, material transfer points, truck bodies, impact curtains, bunkers, silos, chutes and filtering buckets

Specifications

Polymer basis BR/IR/SBR DIN ISO 1629
Specific Weight 1.13 g/cm3 DIN EN ISO 1183-1
Hardness 60 Shore A DIN ISO 7619-1
Colour Black

Product Information

Properties

  • Safe protection against wear and material build-up with built-in wear indicator
  • Black wear layer
  • Orange signal layer
  • Excellent wear resistance to dry abrasion
  • and impact
  • Very elastic
  • High self-cleaning effect
  • Noise damping; reduces dust formation
  • Good weather resistance
  • CN bonding layer provides fast and good
  • adhesion

Area of Application

  • Especially suitable for conveying components that are hard to access and inspect by conventional methods
  • Lining of drains, pipes, hydrocyclones, flotation cells, tanks, etc for example in the sand and gravel industry

Specifications

Polymer basis BR/IR/SBR DIN ISO 1629
Specific Weight 1.13 g/cm3 DIN EN ISO 1183-1
Hardness 60 Shore A DIN ISO 7619-1
Colour Black/Orange

Product Information

Properties

  • Oil and grease resistant REMALINE 70 premium quality
  • Superior resistance to wear
  • Excellent resistance to abrasion
  • Extremely high tensile strength
  • Good weather resistance
  • CN bonding layer provides fast and good adhesion

Area of Application

  • Material transfer points, chutes, bunkers and slides
  • Lining for truck bodies, impact curtains and vibrating conveyors

Specifications

Polymer basis NBR DIN ISO 1629
Specific Weight 1.15 g/cm3 DIN EN ISO 1183-1
Hardness 59 Shore A DIN ISO 7619-1
Colour Black

Product Information

Properties

  • Fabric reinforced, oil and grease resistant REMALINE 70 premium quality
  • Superior resistance to wear
  • Excellent resistance to abrasion
  • Extremely high tensile strength
  • Good weather resistance
  • CN bonding layer provides fast and good adhesion

Area of Application

  • Material transfer points, chutes, bunkers and slides
  • Lining for truck bodies, impact curtains and vibrating conveyors

Specifications

Polymer basis NBR DIN ISO 1629
Specific Weight 1.15 g/cm3 DIN EN ISO 1183-1
Hardness 59 Shore A DIN ISO 7619-1
Colour Black

Product Information

Properties

  • Self-extinguishing, antistatic REMALINE 70 premium quality
  • Moderate oil resistance
  • Superior resistance to wear
  • Excellent resistance to abrasion
  • Extremely high tensile strength
  • Good weather resistance
  • CN bonding layer provides fast and good adhesion

Area of Application

  • Material transfer points, chutes, bunkers and slides
  • Lining for truck bodies, impact curtains and vibrating conveyors
  • Lagging for non-driven pulleys with moderate to high belt traction
  • Cold refurbishing of conveyor belts • Mill lining

Specifications

Polymer basis CR DIN ISO 1629
Specific Weight 1.39 g/cm3 DIN EN ISO 1183-1
Hardness 60 Shore A DIN ISO 7619-1
Electric resistance Antistatic
Inflammability Self-extinguishing
CN bonding layer Conductive (black)
Colour Black

Product Information

Properties

  • Heat resistant REMALINE 70 premium quality up to 110 °C, short peaks up to 130 °C
  • Superior resistance to wear
  • Excellent resistance to abrasion
  • Extremely high tensile strength
  • Good weather resistance
  • CN bonding layer provides fast and good adhesion

Area of Application

  • Material transfer points, chutes, bunkers and slides
  • Lining for truck bodies, impact curtains and vibrating conveyors
  • Lagging for non-driven pulleys with mo- derate to high belt tension
  • Mill lining

Specifications

Polymer basis BR/IR DIN ISO 1629
Specific Weight 1.11 g/cm3 DIN EN ISO 1183-1
Hardness 60 Shore A DIN ISO 7619-1
Max. temperature Up to 110°C, short peaks up to 130°C
Colour Black

Product Information

Properties

  • Oil and grease resistant REMALINE 70 premium quality
  • Food quality
  • Superior resistance to wear
  • Excellent resistance to abrasion
  • Extremely high tensile strength
  • Good weather resistance
  • CN bonding layer provides fast and good adhesion

Area of Application

  • Material transfer points, chutes, bunkers and slides
  • Lining for truck bodies, impact curtains and vibrating conveyors
  • Lagging for non-driven pulleys with mo- derate to high belt tension

Specifications

Polymer basis NBR DIN ISO 1629
Specific Weight 1.22 g/cm3 DIN EN ISO 1183-1
Hardness 56 Shore A DIN ISO 7619-1
Colour White

Product Information

Properties

  • Safe protection against material flow problems
  • Extraordinary hard and smooth surface
  • Smoothness increases during operation
  • Good weather resistance
  • Workable after warming up
  • CN bonding layer provides fast and good adhesion

Area of Application

  • Especially suitable for lining and coating in foundries, steel mills and glass recycling plants
  • Improves flow of material in chutes with fine, grainy materials
  • Lining of sliding surfaces
  • Lining for electro-magnetic vibratory feeders
  • Discharge chutes for waste slag

Specifications

Polymer basis NR/BR DIN ISO 1629
Specific Weight 1.13 g/cm3 DIN EN ISO 1183-1
Hardness 88 Shore A DIN ISO 7619-1
Colour Black

Product Information

Properties

  • Excellent abrasion resistance
  • High resistance to wear caused by cutting and grooving
  • Resistant to oils, grease and many solvents
  • Remains flexible even at low temperatures
  • CN bonding layer provides fast and lasting adhesion

Area of Application

  • Lining of vibration chutes, slides, silos, bunkers
  • Wear protection of magnetic belts

Specifications

Polymer basis TPU DIN ISO 1629
Specific Weight 1.20 g/cm3 DIN EN ISO 1183-1
Hardness 85 Shore A DIN ISO 7619-1
Colour Red

Product Information

Properties

  • Wear-resistant
  • Good elasticity
  • Green contact layer (KS)

Area of Application

  • Protection against minor, wet wear

Specifications

Polymer basis NR/SBR DIN ISO 1629
Hardness 45 Shore A DIN ISO 7619-1
Colour Black

Product Information

Properties

  • Wear-resistant
  • Good tear growth resistance
  • Green contact layer (KS)

Area of Application

  • Protection against minor, dry wear

Specifications

Polymer basis NR/BR/SBR DIN ISO 1629
Hardness 61 Shore A DIN ISO 7619-1
Colour Black

Product Information

Properties

  • High resistance to wear
  • Oil and grease resistant
  • Resists hydrolysis
  • Resists microbes
  • High impact elasticity
  • High notch value
  • Temperaturerangefrom-30°Cto+80°C
  • CN bonding layer provides fast and lasting adhesion

Area of Application

  • Oil-, grease- and wear-resistant lining
  • Prevents caking and noise
  • Slides and chutes
  • Slip ground containers

Specifications

Polymer basis PUR DIN ISO 1629
Specific Weight 1.22 g/cm3 DIN EN ISO 1183-1
Hardness 65 Shore A DIN ISO 7619-1
Colour Green

Product Information

Properties

  • Excellent resistance to wear
  • Oil and grease resistant
  • Resists hydrolysis
  • Resists microbes
  • High impact elasticity
  • High notch value
  • Temperaturerangefrom-30°Cto+80°C
  • CN bonding layer provides fast and lasting adhesion

Area of Application

  • Oil-, grease- and wear-resistant lining Prevents caking and noise
  • Slides and chutes
  • Slip ground containers
  • Concrete discharge chutes

Specifications

Polymer basis PUR DIN ISO 1629
Specific Weight 1.22 g/cm3 DIN EN ISO 1183-1
Hardness 75 Shore A DIN ISO 7619-1
Colour Green

Product Information

Properties

  • High resistance to wear
  • Oil and grease resistant
  • Resists hydrolysis
  • Resists microbes
  • High impact elasticity
  • High notch value
  • Temperaturerangefrom-30°Cto+80°C
  • CN bonding layer provides fast and lasting adhesion

Area of Application

  • Oil-, grease- and wear-resistant lining
  • Prevents caking and noise
  • Slides and chutes
  • Concrete discharge chutes

Specifications

Polymer basis PUR DIN ISO 1629
Specific Weight 1.23 g/cm3 DIN EN ISO 1183-1
Hardness 90 Shore A DIN ISO 7619-1
Colour Green

Product Information

Properties

  • Approved under FDA (FDA CFR 21§ 177.2600)
  • Approved under (VO (EG) 1935/2004, VO (EU) 10/2011)
  • Operating temperature up to 70°C
  • High resistance to wear
  • Oil and grease resistant
  • CN bonding layer provides fast and long lasting adhesion

Area of Application

  • Oil, grease and wear-resistant lining
  • Prevents caking and noise
  • Chutes and slides
  • Loading facilities
  • Food industry

Specifications

Polymer basis PUR DIN ISO 1629
Specific Weight 1.21 g/cm3 DIN EN ISO 1183-1
Hardness 85 Shore A DIN ISO 7619-1
Colour Blue

Product Information

Properties

  • High resistance to wear
  • Oil and grease resistant
  • Resists hydrolysis
  • Resists microbes
  • High impact elasticity
  • High notch value
  • Temperature range from -30°C to +70°C
  • Reinforced by perforated metal insert
  • Easy to screw

Area of Application

  • Oil, grease and wear-resistant lining
  • Prevents caking and noise
  • Chutes and slides
  • Concrete discharge funnels and transfer points
  • Impact elements
  • Component linings

Specifications

Polymer basis PUR DIN ISO 1629
Specific Weight 1.23 g/cm3 DIN EN ISO 1183-1
Hardness 75 Shore A DIN ISO 7619-1
Colour Green

Enquire Today
